Gates G1 MegaSys hydraulic hose, supplied by Twin Hydraulics Engineering.
| Brand | Gates |
| Tube | NBR (Nitrile) based. |
| Cover | NBR/PVC based. MSHA approved. |
| Temperature | -40°C to +100°C. For water emulsions, etc. see Engineering and technical data page 292. |
| Max working pressure | 3700 psi |
| Standards | Exceeds ISO 1436 1SN R1ATS. EN 853 1SN. SAE 100R1AT. |
Sizes
| Size | DN | Working | Burst | Part no. |
|---|---|---|---|---|
| -4 | DN6 | 3250 psi | 13000 psi | 4G1 |
| -5 | DN8 | 3100 psi | 12400 psi | 5G1 |
| -6 | DN10 | 2600 psi | 10400 psi | 6G1 |
| -8 | DN12 | 2325 psi | 9300 psi | 8G1 |
| -10 | DN16 | 1900 psi | 7600 psi | 10G1 |
| -12 | DN19 | 1525 psi | 6100 psi | 12G1 |
| -16 | DN25 | 1275 psi | 5100 psi | 16G1 |
| -20 | DN31 | 3700 psi | psi | 20G1 |
| -24 | DN38 | 2900 psi | psi | 24G1 |
| -32 | DN51 | 2400 psi | psi | 32G1 |
