HANSA-FLEX HD 800 hydraulic spiral hose, supplied by Twin Hydraulics Engineering.
About this hose: Spiral hose, exceeds SAE 100 R15.
| Brand | HANSA-FLEX |
| Series | HD 800 |
| Type | Spiral Hose |
| Standard | SAE 100 R15 |
| Inner tube | oil resistant, synthetic rubber |
| Reinforcement | four to six high-tensile steel wire spirals |
| Availability | Ex-stock / on request — request a quote |
Available sizes
| Part | DN | Size | Working pressure | Burst pressure | Min. bend radius |
|---|---|---|---|---|---|
| HD 816 | 16 | 5/8″ | 500 bar | 2,000 bar | 200 mm |
| HD 820 | 19 | 3/4″ | 500 bar | 2,000 bar | 215 mm |
| HD 825 | 25 | 1″ | 500 bar | 2,000 bar | 270 mm |
| HD 832 | 31 | 1.1/4″ | 500 bar | 2,000 bar | 380 mm |
